RUBBER ROLLS

For indoor sport courts, we have two recommended models:  Tayapro and Tayaplus. For these two models, before installing the modular tiles, a layer of rubber rolls is very necessary.

On the one hand, the rubber roll layer could help improve the shock absorption ability of the court surface, which could protect players' knees and ankles effectively, on the other hand, it could help decrease the knocking noise between the modular tiles and the ground. Additionally, as the rubber rolls have elasticity, it could provide a more flat sub-base for the modular tiles, which makes the court surface more stable and flat after installation.

Usually we recommend 3mm thickness rubber rolls, if the thickness is too small, the rubber rolls will broke easily, if the thickness is larger, the cost will be higher. The already installed indoor sport courts have proved 3mm thickness is a wise option.

The rubber rolls choose to use 100% recycled raw materials, no pungent smell, and has vert excellent durability, not easy to tear up, which could guarantee the sub-base keep in a very good condition after years of use.

We believe that the rubber rolls will bring your sport court more comfort, safety, and it could bring you a professional sport court level feeling.





INSTALLATION:

1. Clean the ground: before laying the rubber rolls, the workers will need to clean the ground firstly, making sure there is no rubbish or little rocks on the ground.

2. Unfold the rubber rolls: put the rubber rolls in the right place, unfold the rubber rolls, and let the rubber rolls have a rest for at last 24 hours before laying.

3. Laying the rubber rolls: pull the rubbers to the correct place, make sure there is no obvious gap between neighboring rubber rolls, and cut down redundant parts.

4. Assembling the tiles: assemble the modular tiles according to the court design. It is a good choice to assemble the modular tiles with a rubber hammer.

Pay attention: the workers should not smoke during the installation process, and make sure keep the indoor sport court away from fire and other high temperature materials.




SPECIFICATION:

Model No: Rubber Rolls

Raw Materials: recycled SBR granules

Thickness: 3mm ~ 10mm ( 3mm recommended )

Roll Width: 1m / 1.25m

Roll Length: 15m / 25m ( customized )

Color: Black ( colorful EPDM flecks optive)

Advantages: shock absorptive, noise absorptive, anti-slip,etc.

Application: Indoor court flooring sub-base

Installation: no need of glue

Life Guarantee: 5 years
